IP20-10mm PCB 2P COB/SMD Connector
- Brief Info
- Types: Strip to Strip Joint, strip to power, strip to strip bridge, L shape, T shape
- Applicable Strip: 10MM 2P IP20 led strip light
- Workable PCB Type: Flexible
- Workable Wire: 20 AWG/0.52 mm2
- Certificate: CE, RoHS
Option
| Item No | Model No | Picture | Types | Aplication |
| 22# | HR-S-SC-2PIN-10MM-A |   | Strip to strip Joint; | Used for 10mm 2P IP20 COB strip light |
| 21# | HR-S-SC-2PIN-10MM-B |   | Strip to wire, with 20AWG wire. | Used for 10mm 2P IP20 COB strip light |
| 23# | HR-S-SC-2PIN-10MM-C |   | Strip to Strip Bridge | Used for 10mm 2P IP20 COB strip light |
| 150# | HR-S-SC-2PIN-10MM-L |   | Strip to strip L shape | Used for 10mm 2P IP20 COB strip light |
| 152# | HR-S-SC-2PIN-10MM-T |   | Strip to strip T shape | Used for 10mm 2P IP20 COB strip light |
Data Sheet
Used for 10mm 2P IP20 COB/SMD strip light
| Model No. | Type | Compatible Led Strip | Voltage/Current | size | material | wire cable | Color |
| 22# HR-S-SC-2PIN-10MM-A | Strip to Strip Joint | 10mm 2P COB/SMD IP20 strip light | 5-48V/6A | 13.5x11.5x3.7mm | PC+Copper | / | Transparent |
| 21# HR-S-SC-2PIN-10MM-B | Strip to Wire | 10mm 2P COB/SMD IP20 strip light | 5-48V/6A | 13.5x11.5x4.2mm | PC+Copper | 150MM Length 20AWG/0.52mm² | Transparent |
| 23# HR-S-SC-2PIN-10MM-C | Strip to Strip Bridge | 10mm 2P COB/SMD IP20 strip light | 5-48V/6A | 13.5x11.5x4.2mm | PC+Copper | 150MM Length 20AWG/0.52mm² | Transparent |
| 150# HR-S-SC-2PIN-10MM-L | Strip to Strip L Shape | 10mm 2P COB IP20 strip light | 5-48V/5A | 18.6x11.6x3.55mm | PC+Copper | / | Transparent |
| 152# HR-S-SC-2PIN-10MM-T | Strip to Strip T Shape | 10mm 2P COB IP20 strip light | 5-48V/5A | 20x12x4.2mm | PC+Copper | / | Milky white |
